H-19S Smart Touch Polyurethane Spray Foam & Polyurea Spray Machine

H-19S Smart Touch polyurethane foam & polyurea spray machine is a 5th generation hydraulic proportioner

The h19s smart touch polyurethane foam spray machine, which has an innovative 10-inch touchscreen, records its daily performance and all possible malfunctions.

H-19S Smart Touch polyurethane foam spray machine makes your work easy and controlled with the data in its memory.

Catalog

Technical

Question

Polyurethane Spray Foam & Polyurea Spray Machine Quality

Grow your business together

Don't forget to buy high quality spray equipment with the best price with the H-19S Smart Touch polyurethane spray machine!

Spray Foam Insulation Guns

It is the only and most robust isolation gun made of solid aluminum in the world.

Explore spray gun

Polyurethane equipment

Spray Foam Insulation Equipment

We are manufacturer and supplier of spray foam systems and spray insulation unit.

Explore all equipment

Best prices & quality

Barrel Transfer Pump

Explore transfer pump

A polyurethane spray foam & polyurea spray machine that stands out when it comes to power, durability and efficiency

This state-of-the-art technology, where you can see all the errors that occur in the system with the pressure balancing system, will be your biggest assistant in occupational safety and quality.

The only competitor of the H-19S Smart Touch polyurethane spray foam machine, which comes to mind first when it comes to power, durability and maximum efficiency, is itself.

Polyurethane Spray Foam & Polyurea Spray Machine Certificate

Warranty: 2 year

Spare part Possesion: 10 year

Technology: Industry 4.0

Output Flow: 12-19 kg/min

Get to know this wonderful spray foam machine better in just 1 minute.

High power and a+ customer service

Why you should choose?

Why choose this polyurethane machine?

Intelligent system memory

With the advanced memory recording system, it keeps in memory how much polyurethane foam or polyurea sprayed monthly, providing great convenience.

Intelligent digital display

Even if the analog gauges fail, it does not let you down and allows you to see all the pressure values on the screen digitally.

Robotic working system

Robot matching can be done in mass production facilities with advanced industry 4.0 hardware and software.

Polyurethane Spray Foam & Polyurea Spray Machine Manufacturer

Why you should choose?

Can't decide which spray machine to buy?

All technical information of H-19S Smart Touch polyurethane machine

(*) Please indicate the voltage information of the machine to our customer representative when ordering.

	Europe-Asia-Africa-Australia	America
Volt	350-415	220-240
Max KW	23 (23.000 W)	23 (23.000 W)
Ampere	45	54
Phase	3 Ø Y	3 Ø Δ
Hz	50	60
Generator(KW)	33	33
Maximum Fluid Output (25°C ambient temp)	12-19 kg/dk	12-19 kg/dk
Max. Fluid Pressure (25°C ambient temp)	1,5 MPa, 150 bar, 2175 Psi veya 2.4 MPa, 2,45 MPa, 245 bar, 3553 Psi	1,5 MPa, 150 bar, 2175 Psi veya 2.4 MPa, 2,45 MPa, 245 bar, 3553 Psi
Adjustable Fluid Pressure	30 bar - 150 - 240 bar	30 bar - 150 - 240 bar
Oil Pressure	72 bar	72 bar
Preheater (KW)	7,5	7,5
Hose Heating (KW	4	4
Fluid Output (ISO)	16-1.5 metric	1/2 Unf
Fluid Output (POLY)	18-1.5 metric	9/16 Unf
Fluid Input (ISO)	(G) 3/4 (2.0 MPa, 20 bar) max.	(Npt) 3/4 (2.0 MPa, 20 bar) max.
Fluid Input (POLY)	(G) 3/4 (2.0 MPa, 20 bar) max.	(Npt) 3/4 (2.0 MPa, 20 bar) max.
Max. Fluid Temperature	90°C / 194°F	90°C / 194°F
Max. Hose Length (Mt.)	120	120
Hydraulic Oil Capacity(Lt.)	34	34
Net Weight	270 kg (270.000 gr.)	270 kg (270.000 gr.)

Voltage Codes
Ø	PHASE
Δ	DELTA
Y	WYE

(*) All measurements has been made while equipments work at full power.

H-19S Smart Touch frequently asked questions

Are there different language options on the screen?
Turkish, English, Arabic, French, Dutch, German, Spanish and Russian language options are available.
Is it possible to access the machine remotely in case of failure?
In cases where remote access information is shared, we provide remote support to every part of the world.
Is it possible to connect to the machine with a mobile phone?
This is not allowed due to the inconveniences of a disconnection after the connection with the mobile phone has been established.
Is it right to use these polyurethane spray foam and polyurea machines in variable job sites?
In variable work sites, these machines can be exposed to variable energy, so we recommend using the analog series (Evopur H Series).
